Tubes

Available Types:

Nominal voltage [kV]: 160 kV

Focal spot, EN [mm]: 0.4 – 4.0 mm

Max. power [W]: 1000 W

Beam type: Panoramic

Product series: MXR Standard

MXR 75 HP 20 FB

Nominal voltage [kV]: 75 kV

Focal spot, EN [mm]: 1.0 mm

Max. power [W]: 1000 W

Beam type: Fan Beam

Product series: MXR High Power

Nominal voltage [kV]: 90 kV

Focal spot, EN [mm]: 1.0 mm

Max. power [W]: 1000 W

Beam type: Fan Beam

Product series: MXR High Power

MXR 75 HP 20

Nominal voltage [kV]: 75 kV

Focal spot, EN [mm]: 1.0 mm

Max. power [W]: 1000 W

Beam type: Directional

Product series: MXR High Power

MXR 75 30

Nominal voltage [kV]: 75 kV

Focal spot, EN [mm]: 5.5 mm

Max. power [W]: 1000 W

Beam type: Directional

Product series: MXR Standard

MXR 601 HP 11

Nominal voltage [kV]: 600 kV

Focal spot, EN [mm]: 0.7 – 2.0 mm

Max. power [W]: 700 – 1500 W

Beam type: Directional

Product series: MXR High Power

MXR 500 HP 11

Nominal voltage [kV]: 500 kV

Focal spot, EN [mm]: 0.4 – 1.0 mm

Max. power [W]: 700 – 1500 W

Beam type: Directional

Product series: MXR High Power

MXR 452 Y

Nominal voltage [kV]: 450 kV

Focal spot, EN [mm]: 2.5 – 5.5 mm

Max. power [W]: 900 – 4500 W

Beam type: Fan beam

Product series: MXR Standard

MXR 451 HP 11

Nominal voltage [kV]: 450 kV

Focal spot, EN [mm]: 0.4 – 1.0 mm

Max. power [W]: 700 – 1500 W

Beam type: Directional

Product series: MXR High Power

MXR 451 26

Nominal voltage [kV]: 450 kV

Focal spot, EN [mm]: 2.5 – 5.5 mm

Max. power [W]: 900 – 4500 W

Beam type: Directional

Product series: MXR Standard

MXR 450 XP 15 20 20

Nominal voltage [kV]: 450 kV

Focal spot, EN [mm]: 2.0 – 2.0 mm

Max. power [W]: 1800 – 1800 W

Beam type: Directional

Product series: MXR Xtra Performance

MXR 421 HP 11

Nominal voltage [kV]: 450 kV

Focal spot, EN [mm]: 0.4 – 1.0 mm

Max. power [W]: 700 – 1500 W

Beam type: Directional

Product series: MXR High Power

MXR 421 26

Nominal voltage [kV]: 420 kV

Focal spot, EN [mm]: 2.5 – 5.5 mm

Max. power [W]: 900 – 4500 W

Beam type: Directional

Product series: MXR Standard

MXR 350 26 90

Nominal voltage [kV]: 350 kV

Focal spot, EN [mm]: 3.0 – 5.5 mm

Max. power [W]: 1500 – 4200 W

Beam type: Directional

Product series: MXR Standard

MXR 350 26

Nominal voltage [kV]: 350 kV

Focal spot, EN [mm]: 3.0 – 5.5 mm

Max. power [W]: 1500 – 4200 W

Beam type: Directional

Product series: MXR Standard

MXR 350 23 90

Nominal voltage [kV]: 350 kV

Focal spot, EN [mm]: 1.9 – 3.6 mm

Max. power [W]: 640 – 1600 W

Beam type: Directional

Product series: MXR Standard

MXR 321

Nominal voltage [kV]: 320 kV

Focal spot, EN [mm]: 8 mm

Max. power [W]: 4000 W

Beam type: Directional

Product series: MXR Standard

MXR 320 HP 11 FB 90

Nominal voltage [kV]: 320 kV

Focal spot, EN [mm]: 0.4 – 1.0 mm

Max. power [W]: 800 – 1800 W

Beam type: Fan Beam

Product series: MXR High Power

MXR 320 HP 11 FB

Nominal voltage [kV]: 320 kV

Focal spot, EN [mm]: 0.4 – 1.0 mm

Max. power [W]: 800 – 1800 W

Beam type: Fan Beam

Product series: MXR High Power

MXR 320 HP 11 AX

Nominal voltage [kV]: 320 kV

Focal spot, EN [mm]: 0.4 – 1.0 mm

Max. power [W]: 800 – 1800 W

Beam type: Directional

Product series: MXR High Power

MXR 320 HP 11 90

Nominal voltage [kV]: 320 kV

Focal spot, EN [mm]: 0.4 – 1.0 mm

Max. power [W]: 800 – 1800 W

Beam type: Directional

Product series: MXR High Power

MXR 320 HP 11

Nominal voltage [kV]: 320 kV

Focal spot, EN [mm]: 0.4 – 1.0 mm

Max. power [W]: 800 – 1800 W

Beam type: Directional

Product series: MXR High Power

MXR 320 26 AX

Nominal voltage [kV]: 320 kV

Focal spot, EN [mm]: 3.0 – 5.5 mm

Max. power [W]: 1500 – 4200 W

Beam type: Directional

Product series: MXR Standard

MXR 320 26 90

Nominal voltage [kV]: 320 kV

Focal spot, EN [mm]: 3.0 – 5.5 mm

Max. power [W]: 1500 – 4200 W

Beam type: Directional

Product series: MXR Standard

MXR 320 26

Nominal voltage [kV]: 320 kV

Focal spot, EN [mm]: 3.0 – 5.5 mm

Max. power [W]: 1500 – 4200 W

Beam type: Directional

Product series: MXR Standard

MXR 320 23 AX

Nominal voltage [kV]: 320 kV

Focal spot, EN [mm]: 1.9 – 3.6 mm

Max. power [W]: 640 – 1600 W

Beam type: Directional

Product series: MXR Standard

MXR 320 23 90

Nominal voltage [kV]: 320 kV

Focal spot, EN [mm]: 1.9 – 3.6 mm

Max. power [W]: 640 – 1600 W

Beam type: Directional

Product series: MXR Standard

MXR 320 23

Nominal voltage [kV]: 320 kV

Focal spot, EN [mm]: 1.9 – 3.6 mm

Max. power [W]: 640 – 1600 W

Beam type: Directional

Product series: MXR Standard

MXR 226

Nominal voltage [kV]: 225 kV

Focal spot, EN [mm]: 7.5 mm

Max. power [W]: 3000 W

Beam type: Directional

Product series: MXR Standard

MXR 225 XP 15 15 15

Nominal voltage [kV]: 225 kV

Focal spot, EN [mm]: 1.5 – 1.5 mm

Max. power [W]: 2250 – 2250 W

Beam type: Directional

Product series: MXR Xtra Performance

MXR 225 MF

Nominal voltage [kV]: 225 kV

Focal spot, EN [mm]: 0.05 – 0.2 mm

Max. power [W]: 50 – 200 W

Beam type: Directional

Product series: MXR MesoFocus

MXR 225 HP 11 FB

Nominal voltage [kV]: 225 kV

Focal spot, EN [mm]: 0.4 – 1.0 mm

Max. power [W]: 800 – 1800 W

Beam type: Fan Beam

Product series: MXR High Power

MXR 225 HP 11

Nominal voltage [kV]: 225 kV

Focal spot, EN [mm]: 0.4 – 1.0 mm

Max. power [W]: 800 – 1800 W

Beam type: Directional

Product series: MXR High Power

MXR 225 26

Nominal voltage [kV]: 225 kV

Focal spot, EN [mm]: 1.2 – 5.5 mm

Max. power [W]: 600 – 4500 W

Beam type: Directional

Product series: MXR Standard

MXR 225 22

Nominal voltage [kV]: 225 kV

Focal spot, EN [mm]: 1.0 – 5.5 mm

Max. power [W]: 640 – 3000 W

Beam type: Directional

Product series: MXR Standard

MXR 225 21

Nominal voltage [kV]: 225 kV

Focal spot, EN [mm]: 1.0 – 3.0 mm

Max. power [W]: 640 – 1600 W

Beam type: Directional

Product series: MXR Standard

MXR 225 02 FB

Nominal voltage [kV]: 225 kV

Focal spot, EN [mm]: 5.5 mm

Max. power [W]: 3000 W

Beam type: Fan Beam

Product series: MXR Standard

MXR 225 01

Nominal voltage [kV]: 225 kV

Focal spot, EN [mm]: 0.5 mm

Max. power [W]: 320 W

Beam type: Directional

Product series: MXR Standard

MXR 165

Nominal voltage [kV]: 160 kV

Focal spot, EN [mm]: 5.5 mm

Max. power [W]: 6000 W

Beam type: Directional

Product series: MXR Standard

MXR 161 FB

Nominal voltage [kV]: 160 kV

Focal spot, EN [mm]: 5.5 mm

Max. power [W]: 4000 W

Beam type: Fan Beam

Product series: MXR Standard

MXR 161

Nominal voltage [kV]: 160 kV

Focal spot, EN [mm]: 7.5 mm

Max. power [W]: 3000 W

Beam type: Directional

Product series: MXR Standard

MXR 160 HP FB

Nominal voltage [kV]: 160 kV

Focal spot, EN [mm]: 1.0 mm

Max. power [W]: 1000 W

Beam type: Fan beam

Product series: MXR High Power

MXR 160 HP 20

Nominal voltage [kV]: 160 kV

Focal spot, EN [mm]: 1.0 – 1.0 mm

Max. power [W]: 1000 – 1000 W

Beam type: Directional

Product series: MXR High Power

MXR 160 HP 11 FB

Nominal voltage [kV]: 160 kV

Focal spot, EN [mm]: 0.4 – 1.0 mm

Max. power [W]: 500 – 1800 W

Beam type: Fan beam

Product series: MXR High Power

MXR 160 HP 11

Nominal voltage [kV]: 160 kV

Focal spot, EN [mm]: 0.4 – 1.0 mm

Max. power [W]: 800 – 1800 W

Beam type: Directional

Product series: MXR High Power

MXR 160 22

Nominal voltage [kV]: 160 kV

Focal spot, EN [mm]: 1.0 – 5.5 mm

Max. power [W]: 640 – 3000 W

Beam type: Directional

Product series: MXR Standard

MXR 160 21

Nominal voltage [kV]: 160 kV

Focal spot, EN [mm]: 1.0 – 3.0 mm

Max. power [W]: 640 – 1600 W

Beam type: Directional

Product series: MXR Standard

MXR 160 20

Nominal voltage [kV]: 160 kV

Focal spot, EN [mm]: 1.0 – 1.0 mm

Max. power [W]: 640 – 640 W

Beam type: Directional

Product series: MXR Standard

MXR 160 01

Nominal voltage [kV]: 160 kV

Focal spot, EN [mm]: 0.5 mm

Max. power [W]: 320 W

Beam type: Directional

Product series: MXR Standard

MXR 101

Nominal voltage [kV]: 100 kV

Focal spot, EN [mm]: 5.5 mm

Max. power [W]: 1000 W

Beam type: Directional

Product series: MXR Standard

MXR 100 HP 20 FB

Nominal voltage [kV]: 90 kV

Focal spot, EN [mm]: 1.0 mm

Max. power [W]: 1000 W

Beam type: Fan beam

Product series: MXR High Power

MXR 100 HP 20

Nominal voltage [kV]: 90 kV

Focal spot, EN [mm]: 1.0 mm

Max. power [W]: 1000 W

Beam type: Directional

Product series: MXR High Power

MXR 100 30

Nominal voltage [kV]: 90 kV

Focal spot, EN [mm]: 5.5 mm

Max. power [W]: 1000 W

Beam type: Directional

Product series: MXR Standard

MXR 100 12

Nominal voltage [kV]: 100 kV

Focal spot, EN [mm]: 5.5 mm

Max. power [W]: 3000 W

Beam type: Directional

Product series: MXR Standard

MXC 453HP 11

Nominal voltage [kV]: 450 kV

Focal spot, EN [mm]: 0.4 – 1.2 mm

Max. power [W]: 700 – 1200 W

Beam type: Directional

Product series: MXC High Power

MXC 451

Nominal voltage [kV]: 450 kV

Focal spot, EN [mm]: 7.5 mm

Max. power [W]: 800 W

Beam type: Directional

Product series: MXR Standard

MXC 450 MF

Nominal voltage [kV]: 450 kV

Focal spot, EN [mm]: 0.06 – 0.45 mm

Max. power [W]: 50 – 450 W

Beam type: Directional

Product series: MXR MesoFocus

CXR 150

Nominal voltage [kV]: 150 kV

Focal spot, EN [mm]: 2.0 mm

Max. power [W]: 1000 W

Beam type: Directional

Product series: CXR

CXR 105

Nominal voltage [kV]: 100 kV

Focal spot, EN [mm]: 3.0 mm

Max. power [W]: 1000 W

Beam type: Directional

Product series: CXR

CXR 102

Nominal voltage [kV]: 100 kV

Focal spot, EN [mm]: 2.0 mm

Max. power [W]: 600 W

Beam type: Directional

Product series: CXR

MXR 100 24 10 30 (XMB)

Nominal voltage [kV]: 100 kV

Focal spot, EN [mm]: 1.0 – 3.0 mm

Max. power [W]: 640 – 1500 W

Beam type: Directional

Product series: XMB

MXR 160 22 (XMB)

Nominal voltage [kV]: 160 kV

Focal spot, EN [mm]: 1.0 – 5.5 mm

Max. power [W]: 640 – 3000 W

Beam type: Directional

Product series: XMB

MXR 160 21 (XMB)

Nominal voltage [kV]: 160 kV

Focal spot, EN [mm]: 1.0 – 3.0 mm

Max. power [W]: 640 – 1600 W

Beam type: Directional

Product series: XMB

MXR 160 20 (XMB)

Nominal voltage [kV]: 160 kV

Focal spot, EN [mm]: 1.0 – 1.0 mm

Max. power [W]: 640 – 640 W

Beam type: Directional

Product series: XMB

MXR 160 HP 20 (XMB)

Nominal voltage [kV]: 160 kV

Focal spot, EN [mm]: 1.0 – 1.0 mm

Max. power [W]: 1000 – 1000 W

Beam type: Directional

Product series: XMB

MXR 160 HP 11 (XMB)

Nominal voltage [kV]: 160 kV

Focal spot, EN [mm]: 0.4 – 1.0 mm

Max. power [W]: 800 – 1800 W

Beam type: Directional

Product series: XMB

MXRP 160 C (XMB)

Nominal voltage [kV]: 160 kV

Focal spot, EN [mm]: 0.4 – 4.0 mm

Max. power [W]: 1000 W

Beam type: Panoramic

Product series: XMB

MXR 225 22 (XMB)

Nominal voltage [kV]: 225 kV

Focal spot, EN [mm]: 1.0 – 5.5 mm

Max. power [W]: 640 – 3000 W

Beam type: Directional

Product series: XMB

MXR 225 21 (XMB)

Nominal voltage [kV]: 225 kV

Focal spot, EN [mm]: 1.0 – 3.0 mm

Max. power [W]: 640 – 1600 W

Beam type: Directional

Product series: XMB

MXR 225 HP 11 (XMB)

Nominal voltage [kV]: 225 kV

Focal spot, EN [mm]: 0.4 – 1.0 mm

Max. power [W]: 800 – 1800 W

Beam type: Directional

Product series: XMB
